SKKL-D

Product Name

LED Illuminated Magnifier

Model

SKKL-D(Fixed-type desk holder illuminated magnifier)

Product Description

The SKKL-D LED Magnifier is a compact, flange-mounted illuminated magnifier. Equipped with a slim, LED-exclusive head, the magnifier uses board-mounted high CRI LEDs (Ra ≥ 90) that provide bright, natural lighting with low heat generation — ideal for long-duration tasks. The flat diffuser and anti-glare protector ensure uniform light distribution while minimizing strain on the eyes.

Key Features

Flange base LED magnifier for screw-down installation
Ideal for fixed workstations in electronics, R&D, or QC labs
High CRI (≥ 90) LEDs ensure accurate color visibility
Flat diffuser reduces glare and enhances eye comfort
Compact design saves space and supports stable use
On-head switch for seamless control

Lens
Magnifier Lens Magnification Lineup	2x, 3x, 4x, 6x, 8x, 10x, 12x, 15x
AR (anti-reflection) Coated Lens Lineup	Available / 2x, 3x, 4x, 6x, 8x, 10x
Lighting
Light source	High Color Quality White LED(CRI≧90) with Protective cover for diffusion
Input voltage	100～240V: 50/60 Hz: Plug Type A *Change or purchase an additional AC cord to use at 125-240V.Please contact your sales dealer for details.
Power consumption	7W
Dimming Function	Not available
Body
Weight (Kg)	1.1kg (Without lens and AC adapter/body weight)
Vertical /Horizontal Bar (diameter/mm)	ɸ16/ɸ13
AC Adapter	dimension : 96×44×H29[mm] (Not include wires) Weight : 0.3kg(Include wires)
Operating temperature range	5℃ ～ 35℃
Dustproof and waterproof protection grade	IP30 (indoor use only)
